This product page details the versatile power contactor, a reliable 2-pole switching device designed for various electrical control applications. Rated at 20A with a 230VAC control coil, this contactor provides dependable operation for lighting control, heating systems, and motor applications in commercial, industrial, and residential electrical systems.
Overview of the Power Contactor
The 2-pole power contactor serves as an essential component in electrical control systems requiring remote switching capability. Because it can handle significant electrical loads while providing millions of reliable switching operations, it offers an ideal solution for applications where frequent operation and long service life are critical requirements.
Key Features and Technical Specifications
This contactor is engineered for both performance and durability. Therefore, here are its essential characteristics:
- Current Rating: 20A continuous current capacity
- Poles: 2-pole configuration for single-phase or split-phase systems
- Coil Voltage: 230VAC standard control voltage
- Mounting: DIN rail or panel mounting options
- Contact Material: Silver alloy for reliable switching
- Operation: Electromechanical operation with high reliability
- Enclosure: Open-style design for panel installation
- Standards: Compliant with international electrical standards
Typical Applications and Use Cases
The versatile 2-pole design of this power contactor makes it suitable for numerous electrical applications. For example, it is commonly used for:
- Commercial and industrial lighting control
- Electric heating system control
- Single-phase motor control applications
- HVAC system component switching
- Pump and compressor control
- Power distribution switching
- Automated system control circuits
For complete control solutions, explore our range of compatible auxiliary contact blocks and enclosures designed to work with power contactors.
Why Choose This Power Contactor?
Selecting this specific power contactor provides significant advantages for electrical control applications. Firstly, the 20A rating ensures reliable operation with standard electrical loads commonly found in commercial and industrial settings. Secondly, the 230VAC coil voltage allows direct connection to standard mains voltage without requiring additional control transformers, simplifying system design and reducing installation costs. Consequently, you achieve robust power control with straightforward installation for a wide range of electrical applications.
Installation and Wiring Guidelines
Proper installation of this power contactor is essential for optimal performance and safety. Mount the contactor securely on a DIN rail or panel, ensuring adequate clearance for ventilation and maintenance. Use appropriate cable sizes for the 20A rating and ensure all connections are tight and secure. Furthermore, the 230VAC coil can be connected directly to standard mains voltage, but always include appropriate overload protection and control circuit safety measures according to local electrical codes.
For detailed technical specifications and application guidelines, consult the comprehensive Schneider Electric contactor technical documentation.
Enhance Your Electrical Control System Today
In summary, this 2-pole power contactor with its 20A rating and 230VAC coil represents a versatile and reliable solution for various electrical control applications. Finally, by incorporating this robust contactor into your control systems, you ensure reliable operation, enhanced safety, and long service life for your commercial and industrial electrical applications.
