Precise Current Measurement for Electrical Systems
Discover our reliable current transformer 100/5, designed for accurate electrical monitoring in various applications. This efficient transformer converts 100A primary current to a standardized 5A secondary output. Electricians specifically choose this ratio for its versatility in residential, commercial, and light industrial electrical systems.
Versatile Application and Reliable Performance
This current transformer 100/5 delivers consistent performance across multiple electrical environments. The 100/5 ratio provides an ideal balance for moderate current loads commonly found in commercial buildings. Moreover, its compact design allows easy installation in standard electrical panels and distribution boards.
Technical Specifications
Manufacturers designed this current transformer to meet industry standards for accuracy and safety. The 100/5 ratio serves as one of the most common configurations in electrical measurement applications.
- Ratio: 100/5
- Primary Current: 100A
- Secondary Current: 5A
- Application: Electrical measurement and protection
- Standard: Industry-standard 5A secondary output
Ideal for Multiple Measurement Applications
The current transformer 100/5 serves numerous electrical monitoring needs effectively. This ratio proves perfect for sub-metering applications and load monitoring in commercial spaces. Additionally, it provides reliable current sensing for motor protection circuits and generator monitoring systems.
Common Applications and Uses
This versatile current transformer 100/5 finds application across various electrical scenarios. Typical uses include retail store electrical panels, office building distribution systems, and small workshop power monitoring. It also performs reliably in apartment building main supplies and commercial tenant metering installations. For higher current requirements, consider our 200/5 and 400/5 current transformers.
Correct installation ensures accurate current measurement and system safety. Therefore, always follow electrical codes and manufacturer connection guidelines. Additionally, review our current transformer installation guide for proper wiring techniques and safety considerations.
Why Choose Our 100/5 Current Transformer?
We source our 100/5 current transformers from reputable manufacturers who prioritize quality and accuracy. Each unit undergoes testing to ensure reliable performance and measurement precision. The result is a cost-effective solution that provides excellent value for standard electrical applications. When you select our 100/5 current transformer, you invest in reliable current measurement for your electrical systems.
